    Special Custom Common Mode Inductor for New Energy

    Ask Lasest Price
    Brand Name : IKP
    Model Number : High Frequency
    Certification : CE/UL/REACH/ROHS
    Price : 0.01-0.03
    Payment Terms : L/C, T/T
    Supply Ability : 100,000/week
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    Special Custom Common Mode Inductor for New Energy

    Basic Info.

    Working Frequency
    High Frequency
    Structure of Winding
    Single Coil
    Nature of Operation
    Choke Coil
    Structure of Magnetizer
    Ferrite Coil
    Range of Application
    Choke
    Packaging Form
    Power Coils
    Brand
    Ikp
    Inductor Value
    Fixed Inductor
    Transport Package
    Carton
    Trademark
    IKP-ELEC
    Origin
    Hefei, China
    HS Code
    85045000
    Production Capacity
    500000000 Pics/Year

    Product Description

    Key Specifications/Special Features:
    1. High efficiency and High Permeability
    2. High power and Low Frequency Switching
    3. High current
    4. Low power loss
    5. Low temperature rise, Operating Temperature: -55 to 105°C,Max Working Temp: 130°C
    6. Lead wire protected by Teflon tube
    7. Withstand high voltage
    8. High temperature grades are available
    9. Double cores are available
    10. RoHS Compliant
    11. UL insulation systems are available
    12. Reliable
    13. Used in various power supplies
    14. Customized designs are accepted
    15. OEM orders are welcome
    Because of different shapes, sizes, a sense of volume specifications, our products according to customer specific requirements.


    Application:
    1.Low Frequency AC Reactor
    2.Solar Power System
    3.Power Conditioning System
    4.Wind Power System
    5.Automatic Drive Machine
    6.Induction Heater
    7.Welding Machine
    8.Paper Industries
    9.RFI Suppression Choke
    10. DC/DC converters
    11.IP and OP devices


    Special Custom Common Mode Inductor for New Energy
    Electrical Specifications:
    Part NO.InductanceInductance Difference
    (max)
    DC resistance
    (max)
    Rated Current
    (max)
    Dimensions
    (ΦD)
    T6030-752-57.5mH150μH0.1Ω5A0.9mm
    T6030-162-101.6mH100μH0.02Ω10A1.3mm
    T6030-102-141.0mH75μH0.02Ω14A1.5mm
    T6035-201-300.2mH10μH30A2.6mm
    T6035-501-250.5mH15μH25A2.3mm
    T6035-102-201.0mH20μH20A2.0mm
    T6035-162-151.6mH30μH12Ω15A1.8mm
    T3524-302-33mH150μH100Ω3A0.8mm
    T3524-502-35mH200μH130Ω3A0.8mm
    T3524-102-51mH50μH50Ω5A1.0mm
    T3524-202-52mH150μH60Ω5A1.0mm
    T4333-502-55mH200μH55Ω5A1.1mm
    T4333-302-73mH250μH35Ω7A1.3mm
    T4333-102-101mH50μH15Ω10A1.5mm
    T4333-501-150.5mH30μH15A1.8mm
    T5228-102-51mH50μH45Ω5A1.0mm
    T5228-502-55mH200μH95Ω5A1.0mm
    T5228-302-83mH150μH40Ω8A1.2mm
    T5228-102-101mH50μH20Ω10A1.3mm
    T5228-202-102mH80μH25Ω10A1.5mm
    T6332-202-152mH80μH20Ω15A2.0mm
    T6332-152-181.5mH50μH15Ω18A2.1mm
    T6332-102-201mH50μH20A2.3mm
    T6332-501-250.5mH30μH25A2.5mm
    T6340-302-103mH150μH35Ω10A1.5mm
    T6340-202-152mH120μH25Ω15A1.8mm
    T6340-102-201mH50μH10Ω20A2.3mm
    T6340-102-251mH50μH25A2.4mm
    ** We can design and manufacture customized part with specific requirement.
