FEATURES:-High Power
-Low Profile
-Inexpensive Type
-High Reliability
- Low price
- Cost-effective
- High impedance and low loss
-High Conversion Efficiency
-Easily Inserted into PCB
- RoHS compliance and UL
- Custom designs are welcome, Can specify special materials, the
skeleton shape can be customized.
APPLICATION:-DC/DC Converter Transformer
-Current Transformer
-Switching power supply, Adapter and UPS
-Computer products
-DVD
-LED power board
-LCD TV & Monitor Displays Power Boards
-Consumer Electric Products & Battery Charger, Printers
- Specially used in switching power supply and kinds of
high-frequency circuit
- Plays a role in oscillating and separating
SPECIFICATIONS:-Operating Temperature: -25° C to +60° C
-Storage Temperature: -25° C to +85° C
-Operating Humidity: 30 to 95%RH
-Storage Humidity: 30 to 95%RH
Reasons of our top-quality components help your business succeed:
-22 years of experience customizing and power transformers
-Your professional and reliable partner for various electronics
- Over 1000 buyers value our products
-20000m2 factory with 21 production lines and 800 employees
- 5 million units annual capacity
- Our Products has the UL Insulation System, Quality is guaranteed
- High quality and best services
- More models and types are available. Welcome your spec and sample
to make custom-manufacturing.
Kindly Reminder:1. About the SAMPLES. Please provide specific specifications or sample material, we
will evaluate your products, design and produce samples.2. About PRICE. Transformers are custom products, due to the different materials
and design, even if the same model, the price is not the same. The
price also depends on the complexity of the parameters and the
amount of orders.3. About SHIPPING. Samples in 3-5 days; mass production in 7-15 days.4. About PAYMENT. Foreign customers:100% T / T; domestic customers: 30 days after
delivery, according to the invoice payment.5. Packaging, logistics, according to the specific requirements of
the purchase and sale contracts.6. Contact us now for more details:Business hotlines: + 86-551-63748663 63749803
| Type | Shape Structure | Dimension | Power range |
| A | B | C | D | E | F |
| ETD29 | Horizontal | 34.0Max | 24.6±0.5 | 35.2±0.5 | 4.0±0.3 | 5.0±0.3 | 25.8±0.5 | 65W Max |
| ETD34 | 41.0Max | 29.4±0.5 | 40.3±0.5 | 4.0±0.3 | 5.0±0.3 | 25.6±0.5 | 400W Max |
| ETD39 | 46.0Max | 35.3±0.5 | 44.0±0.5 | 4.0±0.3 | 5.0±0.3 | 30.4±0.5 | 500W Max |
| ETD44 | 52.0Max | 39.5±0.5 | 51.0±0.5 | 4.0±0.3 | 5.0±0.3 | 35.8±0.5 | 600W Max |
| ETD49 | 57.0Max | 41.6±0.5 | 57.3±0.5 | 4.0±0.3 | 5.0±0.3 | 40.7±0.5 | 650W Max |
| ETD59 | 69.0Max | 48.3±0.5 | 65.7±0.5 | 4.0±0.3 | 5.0±0.3 | 50.8±0.5 | 2000W Max |
| ETD29 | Vertical | 37.0Max | 39.0±0.5 | 23.8±0.5 | 4.0±0.3 | 5.0±0.3 | 20.3±0.5 | 65W Max |
| ETD34 | 45.0Max | 47.4±0.5 | 23.4±0.5 | 4.0±0.3 | 5.0±0.3 | 20.3±0.5 | 400W Max
|
